Operating Voltage | 5V |
Operating Current | <300mA@5V |
Maximum Current | 1000mA@5V |
Standby Current | < 18mA@5V |
Operating Temperature | -25℃ - 80℃t |
Storage Condition | -30℃～80℃ 0%-95%RH Non-condensing |
Waterproof Grade | IPX7 |
Control Method | UART/485/CAN/Customized |
Main Functions | 1.Unlocking/Locking Command;2、Judgment of the working position of the lock tongue；3、With the lock tongue in the locked state；4、Identify the position and status of the battery； |
Certifications |
